Workboat Anchor, Danforth Type HHP Anchor
- Dawson Group Ltd. - China Manufacturer, Supplier, Factory
| Nominal Weight (kg) | Dimensions (mm) | |||||
| A | B | C | D | E | F | |
| 20 | 130 | 280 | 540 | 370 | 690 | 170 |
| 25 | 135 | 300 | 580 | 400 | 740 | 185 |
| 30 | 148 | 330 | 620 | 430 | 790 | 200 |
| 40 | 160 | 360 | 680 | 470 | 860 | 220 |
| 50 | 172 | 390 | 720 | 510 | 940 | 230 |
| 60 | 186 | 408 | 755 | 535 | 985 | 240 |
| 75 | 200 | 450 | 830 | 590 | 1,080 | 260 |
| 100 | 216 | 490 | 930 | 640 | 1,180 | 290 |
| 120 | 220 | 505 | 970 | 670 | 1,230 | 300 |
| 125 | 234 | 520 | 1,000 | 690 | 1,270 | 310 |
| 150 | 242 | 550 | 1,060 | 732 | 1,348 | 330 |
| 200 | 266 | 600 | 1,150 | 810 | 1,490 | 360 |
| 250 | 294 | 650 | 1,240 | 870 | 1,600 | 390 |
| 276 | 296 | 660 | 1,250 | 885 | 1,620 | 400 |
| 300 | 312 | 690 | 1,320 | 925 | 1,700 | 420 |
| 400 | 342 | 750 | 1,460 | 1,010 | 1,810 | 460 |
| 500 | 368 | 800 | 1,570 | 1,100 | 2,020 | 490 |
| 750 | 414 | 910 | 1,800 | 1,260 | 2,300 | 560 |
| 1,000 | 450 | 980 | 1,980 | 1,380 | 2,540 | 620 |
| 1,250 | 484 | 1,070 | 2,100 | 1,490 | 2,740 | 670 |
| 1,500 | 512 | 1,120 | 2,220 | 1,580 | 2,850 | 700 |
| 2,000 | 560 | 1,130 | 2,440 | 1,730 | 2,910 | 770 |
| 2,500 | 605 | 1,217 | 2,628 | 1,864 | 3,070 | 830 |
| 4,000 | 700 | 1,420 | 3,070 | 2,170 | 3,590 | 970 |
| 5,000 | 735 | 1,482 | 3,200 | 2,270 | 3,840 | 1,020 |
| 6,000 | 800 | 1,620 | 3,500 | 2,480 | 4,100 | 1,100 |
| 7,000 | 840 | 1,696 | 3,680 | 2,590 | 4,180 | 1,150 |
| 8,500 | 864 | 1,740 | 3,930 | 2,590 | 4,390 | 1,180 |
| 10,000 | 940 | 2,000 | 4,030 | 2,590 | 4,640 | 1,280 |
| 16,000 | 1,105 | 2,240 | 4,850 | 3,435 | 5,680 | 1,520 |
| 18,000 | 1,150 | 2,200 | 5,000 | 3,570 | 5,000 | 1,580 |
