BSMA12 Double Bollard
- Dawson Group Ltd. - China Manufacturer, Supplier, Factory, Exporter
Marine bollards have many different types due to different conditions of wharf structure, ship size or other factors. We supply all kinds of marine bollards: double bitt bollard, single bitt bollard, double cross bollard, single cross bollard, kidney type bollard, horn type bollard, T head type bollard, J type bollard, CVI-Bollards, ship cross bollard, welding bollard and so on.
All our products get certificate ISO9001, CCS, BV or other certificates. We aim to provide the best quality product, competitive price, excellent service for our customers. For more information, please feel free to contact us.
| F | Dimension(mm) | Weight(kg) | ||||||||||
| Tube | Plate | L1 | L2 | H1 | H2 | B | D2 | |||||
| M | T | D1 | S | D1 | S | |||||||
| 4.06 | 12 | 140 | 10 | 140 | 10 | 560 | 320 | 200 | 75 | 200 | 150 | 40 |
| 5.85 | 12 | 168 | 10 | 168 | 10 | 720 | 400 | 250 | 90 | 250 | 200 | 66 |
| 7.96 | 17 | 219 | 10 | 219 | 10 | 900 | 500 | 300 | 100 | 300 | 250 | 97 |
| 13.2 | 30 | 273 | 10 | 273 | 10 | 1130 | 630 | 380 | 125 | 380 | 300 | 145 |
| 19.7 | 50 | 324 | 12.5 | 324 | 12.5 | 1430 | 800 | 480 | 150 | 480 | 380 | 309 |
| 33.5 | 100 | 406 | 20 | 406 | 20 | 1800 | 1000 | 600 | 175 | 600 | 480 | 735 |
| 55.4 | 130 | 508 | 20 | 508 | 20 | 2250 | 1250 | 750 | 200 | 750 | 600 | 1148 |
| 82.8 | 160 | 610 | 20 | 610 | 20 | 2830 | 1570 | 940 | 225 | 940 | 730 | 1673 |
Factory & Package Show:
