CB 3062-79 Horizontal Roller Fairlead

Model NO.: CB*3062-79 Seven Roller Fairlead Type D

Quantity:

Product Description

CB 3062-79 Horizontal Roller Fairlead
- Dawson Group Ltd. - China Manufacturer, Supplier, Factory, Exporter

Fairlead with Horizontal Rollers
Fairlead with horizontal rollers, consisting of vertical and horizontal rollers, can guide mooring ropes from any direction. Horizontal roller fairlead, also called universal roller fairlead, is usually located in the deck end. Horizontal roller fairlead can greatly reduce the abrasion of mooring ropes for the rollers fixed around the fairlead.

CB 3062-79 Horizontal Roller Fairlead
CB*3062-79 fairlead with horizontal rollers has 6 types: CB*3060-79 type A, BA, BB, C, D, E. The total number of rollers ranges from 3 to 9. Horizontal roller fairlead is strictly produced according to the standard CB*3062-79. The surface of the rollers do not have any defects which affect its performance and intensity such as cracks, blisters. All the fairleads get the certificate of quality. If you ’ re interested in our fairleads, please feel free to contact us.

Specification of CB*3062-79 Fairlead Type D:
Model Type: CB*3062-79 Seven Roller Fairlead Type D
Material: Cast Steel
Standard : CB*3062-79
Roller No.: 7 Rollers
Steel Cable Dia meters: 19.5mm~68.0mm
Nylon Rope Diameters: 36mm~100mm
Weight: 247kg~5100kg
Certificate: CCS, ABS, BV, LR, NK, RINA

Steel Rope Dia.	Nylon Rope Dia.	E	F	D	d	L	L1	L2	L3	B	B1	B2	H	H1	Weight(kg)
19.5	36	200	150	100	40-0.5	944	716	300	844	238	194	108	508	250	247
22.5	40	200	150	120	50-0.5	1048	776	320	928	280	232	128	552	270	377
26.0	45	200	180	130	55-0.5	1106	810	330	976	304	250	138	606	310	485
32.0	70	220	180	150	65-0.5	1250	910	370	1100	346	288	158	670	330	716
34.5	80	240	200	160	70-0.5	1340	980	400	1180	370	308	168	710	360	849
37.5	85	240	200	180	80-0.5	1450	1040	420	1270	417	345	190	770	380	951
43.0	95	260	210	200	90-0.5	1596	1146	460	1396	459	385	210	820	410	1546
52.0	100	260	220	230	100-0.5	1746	1236	490	1516	521	445	240	910	450	2143
60.5	_	300	240	260	120-0.5	1990	1990	560	1730	590	500	270	1000	500	3134
68.0	_	320	250	320	150-0.5	2330	2330	640	2010	714	620	330	1130	570	5100
