EC Approved Cast Steel Marine Roller Lever Chain Stopper CB/T 3844-2000

EC Approved Cast Steel Marine Roller Lever Chain Stopper CB/T 3844-2000

Model NO.: DS-EC

Quantity:

Product Description

EC Approved Cast Steel Marine Roller Lever Chain Stopper CB/T 3844-2000

- Dawson Group Ltd. - China Manufacturer, Supplier, Factory

Marine Roller Lever Chain Stopper is a simple pawl set in the bow roller . Normally install directly on the deck .EC approved Marine Roller Lever Chain Stopper made by cast steel .

The Marine Cast Steel Roller Lever Chain Stopper is used to control and handle the marine anchor chains to protect them slip out when we sail or casts anchor .The EC approved Cast Steel Marine Chain Stopper device between anchor windlass and hawse pipe.

When our vessel mooring in somewhere .The Cast Steel Roller Lever Chain Stopper deliver the strength of marine anchor and chain to the vessel . Cast Steel Marine Roller Lever Chain Stopper can save the working load and protect the anchor windlass .CB/T 3844-2000 Marine Chain Stopper is approved by GL ,ABS ,CCS etc classification societies.

Product feature of EC approved Marine Roller Lever Chain Stopper

1.Good Price of Roller Lever Chain Stopper

2.Professional technical team

3.One stop purchase service

4.Short delivery time

5.With international certificate

6.12 months guarantee

If you have any other requirements of the Offshore Cast Steel Roller Lever Chain Stopper please let us know.

Nominal DIA	DIA of anchor chain(mm)	L	L1	L2	L3	L4	B	b1	b2	b3	b4	b5	b6	b7	b8	D	d1	d2	d3	d4	h1	h2	h3	t1	t	Weight (kg)
44	42 44	1000	370	400	270	80	380	260	250	240	110	10	180	60	140	484	22	69	70	154	392	281	160	32	12	274
48	46 48	1050	420	450	300	85	446	286	250	266	120		190	65	150	528	26	73	74	456	414	306	170	34	13	351
52	50 52	1100	440	500	320	90	510	310	250	290	130		200	70	165	572	32	77	78	160	440	330	180	36	14	451
56	54 56	1150	450	550	340	92	556	316	250	296	140		210	75	180	600	34	81	84	164	480	354	190	38	15	536
60	58 60	1200	470	570	360	95	610	330	280	310	150		220	80	200	620	38	87	92	170	490	378	200	40	16	651
64	62 64	1250	500	600	370	100	666	346	280	326	160		230	86	220	640	40	94	95	178	520	400	210	42	17	753
68	66 68	1300	550	640	394	105	732	372	280	350	170	11	240	93	230	680	42	101	103	186	540	420	220	45	18	939
73	70 73	1350	570	670	414	110	800	400	280	376	180	12	260	99	240	730	45	109	110	194	580	460	240	48	20	1178
78	76 78	1400	610	700	442	115	865	425	280	399	190	13	280	105	250	780	48	116	117	208	630	490	260	50	22	1422
84	81 84	1460	650	740	475	120	940	454	280	426	200	14	300	112	260	840	50	124	125	220	670	530	280	55	24	1758
90	87 90	1540	710	780	507	135	1030	484	280	454	210	15	340	119	270	900	55	132	133	236	720	570	320	60	26	2171
95	92 95	1600	740	820	535	140	1080	508	280	476	220	16	370	126	275	950	58	139	140	248	760	610	345	65	28	2567
102	97 102	1680	790	870	572	145	1150	540	280	506	230	17	400	134	290	1020	60	148	149	264	800	650	375	70	30	2755
107	105 107	1750	840	900	600	150	1210	569	280	533	240	18	420	139	295	1070	63	154	155	274	860	690	395	75	32	3840
114	111 114	1820	880	940	637	160	1270	598	280	560	250	19	450	147	305	1140	68	163	164	290	910	740	425	80	34	4302
122	117 122	1880	930	1010	679	165	1340	632	280	592	260	20	490	156	325	1220	70	173	174	308	980	790	465	85	36	5326
132	124 132	1960	1000	1080	730	175	1440	674	280	632	270	21	510	167	350	1320	75	185	186	328	1060	860	490	90	38	6244
