Open Type Three-Roller Fairlead
- Dawson Group Ltd. - China Manufacturer, Supplier, Factory, Exporter
Open type three-roller fairlead
Guide roller fairlead is applicable in marine mooring, used to change and guide mooring ropes in a right direction. The surface of roller is smooth to help reduce the abrasion to the mooring ropes. Guide roller with stand has the following types: open type two-roller fairlead, open type three-roller type, closed type two-roller fairlead and closed type three-roller type. All the guide rollers are of high quality and stable performance. If you’re interested in our guide rollers, please feel free to contact us.
Specification:
Model Type: open type three-roller fairlead
Material: Cast Steel/ Cast Iron
Standard: CB*58-83, JIS F 2014-1987
Roller No.: 3 Rollers
Nominal Diameters:150mm~450mm
Certificate: CCS,ABS,BV,LR,NK,RINA
Unit:mm
| Nominal dia | D | L | I | I2 |
| 150 | 150 | 1160 | 420 | 160 |
| 200 | 200 | 1460 | 530 | 200 |
| 250 | 250 | 1740 | 640 | 230 |
| 300 | 300 | 2020 | 750 | 260 |
| 350 | 350 | 2300 | 860 | 290 |
| 400 | 400 | 2580 | 970 | 320 |
| 450 | 450 | 2880 | 1080 | 360 |
Factory & Package Show:
