Y Type dock bollard
- Dawson Group Ltd. - China Manufacturer, Supplier, Factory, Exporter
Our company supplies all kinds of marine dock bollards: Y type dock bollard, T type bollard, S type bollard, Tee head type bollard, Kidney type bollard, horn type bollard, single bitt mooring bollard, double bitt mooring bollard, cross bitt bollard, DIN82607 double bollards,JIS F2001 double bollards,N.S2584 double bollards,BSMA-12 double bollards,VIS 1 double bollards and so on. All our bollards get the approval of ISO9001 and China Classification Society. As a professional supplier of mooring bollards, we can design new products according to customer’s drawing. For more information, please feel free to contact us.
T-Head Dock Bollard
| Product No. | Bolts Quantity | Capacity (tonnes) | Dimensions(mm) | |||||||
| A | B | C | D | E | F | G | H | |||
| DST-001 | 4 | 10 | 200 | 216 | 236 | 160 | 106 | 218 | 120 | 32 |
| DST-002 | 4 | 25 | 245 | 350 | 305 | 250 | 150 | 285 | 127 | 45 |
| DST-003 | 5 | 30 | 290 | 430 | 410 | 360 | 190 | 360 | 150 | 45 |
| DST-004 | 5 | 50 | 365 | 550 | 540 | 430 | 250 | 475 | 200 | 50 |
| DST-005 | 5 | 75 | 430 | 650 | 650 | 520 | 300 | 570 | 235 | 70 |
| DST-006 | 5 | 80 | 415 | 518 | 540 | 430 | 250 | 430 | 245 | 55 |
| DST-007 | 7 | 120 | 490 | 678 | 342 | 600 | 330 | 584 | 290 | 65 |
| DST-008 | 7 | 200 | 520 | 950 | 780 | 680 | 360 | 670 | 306 | 80 |
| DST-009 | 7 | 200 | 600 | 950 | 780 | 680 | 360 | 370 | 386 | 80 |
| DST-010 | 6 | 200 | 656 | 1020 | 930 | 800 | 460 | 830 | 349 | 100 |
Horn type bollard
| Bolts Qty | Capacity (tonne) | Dimension(mm) | |||||||||
| A | B | C | D | E | F | G | H | J | K | ||
| 5 | 40 | 205 | 205 | 160 | 425 | 50 | 480 | 410 | 165 | 460 | 165 |
| 5 | 90 | 300 | 300 | 198 | 510 | 70 | 650 | 650 | 280 | 600 | 230 |
| 7 | 200 | 360 | 360 | 200 | 660 | 100 | 970 | 740 | 356 | 760 | 240 |
| 6 | 200 | 360 | 360 | 200 | 620 | 80 | 780 | 760 | 356 | 760 | 240 |
| 7 | 300 | 440 | 440 | 305 | 685 | 85 | 920 | 900 | 380 | 840 | 280 |
CVI type bollard
| Types | S.WL(T) | A | B | C | D | E | F | G | H |
| CVI-10 | 10 | 540 | 600 | 460 | 475 | 250 | 40 | 190 | 360 |
| CVI-20 | 20 | 540 | 600 | 460 | 475 | 250 | 50 | 190 | 370 |
| CVI-30 | 30 | 540 | 600 | 460 | 475 | 250 | 60 | 190 | 380 |
| CVI-50 | 50 | 650 | 700 | 600 | 570 | 300 | 60 | 230 | 450 |
| CVI-75 | 75 | 670 | 800 | 650 | 620 | 340 | 90 | 260 | 510 |
| CVI-100 | 100 | 810 | 1000 | 750 | 710 | 381 | 100 | 300 | 560 |
| CVI-150 | 150 | 810 | 1000 | 750 | 710 | 381 | 100 | 300 | 600 |
| CVI-200 | 200 | 810 | 1080 | 800 | 700 | 430 | 110 | 398 | 600 |
