Turnbuckle Malleable Commercial Type
- Dawson Group Ltd. - China Manufacturer, Supplier, Factory
Material: Cast malleable steel.
Made by Cast.
Finished: Galv. self-color.
Packing: Gunny bags and then on pallets. (customer are available)
Feature: Made by Cast Steel.
Advantage: Price cheaper then forged Steel.
Benefit: General Using, widely. All commonly purpose
| Item No. | SWL kg | A | B | C | D | E | F | L | Weight each kg |
| DS-TMCT06 DS-TMCT08 DS-TMCT10 DS-TMCT12 DS-TMCT16 DS-TMCT20 DS-TMCT22 DS-TMCT24 | 100 200 300 500 1000 1500 2200 3000 | 6X100mm 8X125mm 10X150mm 12X200mm 16X250mm 20X300mm 22X330mm 24X350mm | 145 185 210 275 345 435 480 555 | 215 280 325 430 540 670 740 830 | 12 14 16 19 23 28 34 36 | 10 12 14 18 24 26 32 36 | 6 8 9 11 14 18 20 21 | 100 125 150 200 250 300 330 350 | 0.06 0.125 0.250 0.480 0.980 1.650 2.350 2.750 |
Turnbuckles made of malleable cast iron combinated with eyes or/and hooks forged, are used to stretch wires and ropes for subordinated loadings (for example wire fence) By this article it can not guaranteed any breaking loads. Therefore during the stretching you must look, if the loading becomes not to big and the parts of the wire stretcher becomes deformed. In the case of a deforming the load as to be decreased at once. Deformed parts have to be replaced. This articles are not suited for lifting /supporting constructions! If the turnbuckle shall have special demands, please use DIN 1480.
Welcome to buy the newest and competitive price DAWSON Turnbuckle Malleable Commercial Type from our factory. We're one of the leading China manufacturers and suppliers, offering you the wholesale service and the OEM service at a discount. With CE certification, our products made in China in stock are high in quality and low in price. Please be free to get the free sample from us.
For further information, please contact us. Email:info@dawson-group.com
Hot Tags: bulk cast malleable steel turnbuckle, low price commercial type turnbuckle, high quality din 1480 turnbuckle, wholesale lashing turnbuckle, buy discount malleable turnbuckle, hot sale galvanized turnbuckles, customized H.D.G. turnbuckle, cheap price hot dipped Galv. turnbuckle, hot dipped galvanized turnbuckle China supplier, steel turnbuckle China manufacturer, standard marine turnbuckle China factory, cast malleable steel turnbuckle China exporter, lashing turnbuckle in stock, lashing turnbuckle free sample, lashing turnbuckle dawson brands, lashing turnbuckle OEM
